This academic work required of a scan geometry so that it could respond to
a use of high-capacity equipment and thus be repeatable and practice.
Through the analysis of parametric geometry and exploring the options of
the figures, a unit development based on structurally Klein surface, thanks to
its double curvature ensures stiffness at each point of the surface, and resolves
the repetition, very simple and effective, thanks to the flatness tangential
edges and self-supporting feature of the piece.
The analysis of the curvature and line of maximum slope gives an idea of
where to concentrate the greatest number of strains of each piece and
triangulation to determine the metal beams subsequently translated.

Read more

Status: School Project
Location: Madrid, ES
